Product Details:
Contact Now
Chat Now
|
| Ride Capacity: | 2 Person | Engine: | 4 Stroke |
|---|---|---|---|
| Transmission Method: | Chain Drive | Transmission: | 5-speed |
| Ignition Method: | CDI | Lubrication Method: | Pressure, Splash |
| Clutch Type: | Multi-plate Wet Clutch, Manual |
Description:
|
DISPLACEMENT: |
197CC |
ENGINE TYPE |
SINGLE CYLINDER, WATER-COOLED, FOUR-STROKE |
|
MAX. POWER: |
10.5Kw/h |
BRAKE: |
FRONT AND REAR DISC |
|
MAX. TORQUE: |
14.5N.m |
IGNITION TYPE: |
CDI |
|
START SYSTEM: |
ELECTRICAL/KICK |
TRANSMISSION: |
CHAIN DRIVE |
|
TYRE: |
FRONT 80/100-21 REAR 100/100-18 |
Minimum Order Quantity: |
96 |
Single-cylinder, four-stroke, water-cooled engine with internal and external balance shafts, 12V/12-pole, 5/6-speed transmission; inverted front fork, single rear center shock absorber with rocker arm, large swingarm, front and rear disc brakes, slatted wheels, rear grab handle, muffler, bumper with engine guard/barrel guard, rear rack, full LED lighting, standard rearview mirrors.
Specifications:
| Item | Parameter |
| Dimensions (Length x Width x Height) | 2120 x820x 1210 |
| Seat Height | 870mm |
| Wheelbase | 1385mm |
| Minimum Ground Clearance | 280mm |
| Maximum Load | 150kg |
| Steering Angle | 40 |
| Side Stand Tilt Angle | 14 |
| Ride Capacity | 2 Person |
| Dry Weight | 96kg |
| Fuel Tank Capacity | 12L |
| Front Braking System | Disc brakes |
| Rear Braking System | Disc brakes |
| Front Tire Size | 80/100-21 |
| Rear Tire Size | 100/100-18 |
| Battery Size | 12V/6.5Ah |
| Engine Type | Single cylinder, air-cooled, four-stroke |
| Engine displacement | 197CC |
| Bore x stroke | 65.5×66.2 |
| Compression ratio | 9.0:1 |
| Maximum power | 10.5Kw/h |
| Maximum torque | 14.5N.m |
| Maximum speed | 100Km/h |
| Start-up acceleration | 10S |
| Overtaking acceleration | 11S |
| Lubrication method | Pressure, Splash |
| Oil volume | 1.2L |
| Clutch type | Multi-plate wet clutch, manual |
| Ignition method | CDI |
| Spark plug | A8RTC |
| Starting method | Electric kick starter |
| Transmission method | Chain drive |
| Final gear ratio | 13:43 |
Frequently Asked Questions:
Q1. About us:
A: Jiangmen Songfeng Import and Export Co., Ltd. is the export arm of our manufacturing facility, Yuanhua Technology Co., Ltd. We provide factory-direct pricing and strict quality control, ensuring you receive competitive products straight from the source.
Q2. Payment Terms:
A: We require 30% deposit to begin production preparation, with the remaining 70% due upon completion before loading.
Q3. Delivery Timeline:
A: Depending on the order quantity, usually around 45 working days.
Q4. Customization:
A: We can meet OEM requirements and, with the customer's authorization, use the customer's brand. Displacement and other configurations can be modified upon request.
Q5. Packaging Parameters:
A: The size of SKD is 1760*460*840mm, and a 40HQ container can hold 96 units.
The size of CKD is 1400*770*440mmmm, and a 40HQ container can hold 147 units.
Q6. Minimum Order Quantity:
A: We usually recommend MOQ a 40HQ, which can be mixed with different complete motorcycles and spare parts. For the first order of small quantity, a quantity of 20GP is also acceptable. Appreciate your understanding that we do not handle retail exports.
Q7. After-sales Service:
We provide 24-hour online support to resolve quality issues at any time and guarantee the supply of all original spare parts to ensure your worry-free after-sales experience.
