22kW 28N·m Single Cylinder Water-Cooled Adventure Motorcycle Off Road Dirt Bike

Description
Ride Capacity: 2 Person Enginev: 4 Stroke
Transmission Method: Chain Drive Transmission: 5/6-speed
Ignition Method: CDI Lubrication Method: Pressure, Splash
Clutch Type: Multi-plate Wet Clutch, Manual

Description:

DISPLACEMENT:

279.5ml

ENGINE TYPE

SINGLE CYLINDER, AIR-COOLED, FOUR-STROKE

MAX. POWER:

22Kw/h

BRAKE:

FRONT AND REAR DISC

MAX. TORQUE:

28N.m

IGNITION TYPE:

CDI

START SYSTEM:

ELECTRICAL/KICK

TRANSMISSION:

CHAIN DRIVE

TYRE:

FRONT 90/90-19 REAR 130/80-17

Minimum Order Quantity:

96



Single-cylinder, four-stroke, water-cooled 12V 12-pole engine; inverted front suspension, rear central single shock absorber with swingarm, large-format swingarm, front and rear disc brakes, aluminum alloy wheels, rear grab handle, bumper, engine guard/crash bar, rear luggage rack, new handlebar guards, full LED lighting, new rearview mirrors.



Specifications:

Item Parameter
Dimensions (Length x Width x Height) 2070x900x1220
Seat Height 880mm
Wheelbase 1345mm
Minimum Ground Clearance 170mm
Maximum Load 150kg
Steering Angle 35
Side Stand Tilt Angle 14
Ride Capacity 2 Person
Dry Weight 126kg
Fuel Tank Capacity 14L
Front Braking System Disc brakes
Rear Braking System Disc brakes
Front Tire Size 90/90-19
Rear Tire Size 130/80-17
Battery Size 12V/5Ah
Engine Type Single-cylinder, water-cooled, four-stroke
Engine displacement 279.5ml
Bore x stroke 74x65
Compression ratio 10:01
Maximum power 22Kw/h
Maximum torque 28N.m
Maximum speed 120Km/h
Start-up acceleration 10S
Overtaking acceleration 12S
Lubrication method Pressure, Splash
Oil volume 1.2L
Clutch type Multi-plate wet clutch, manual
Ignition method CDI
Spark plug A8RTC
Starting method Electric kick starter
Transmission method Chain drive
Final gear ratio 13:43
