Description:
2-stroke 300 water-cooled special engine, Nibi special racing carburetor, front and rear track version disc brakes, front and rear 7 series lightweight straight-pull aluminum alloy wheels, 7 series lightweight aluminum alloy steering column, brake arm, footrest, cradle, etc. are made of CNC aluminum alloy, special frame. K23 special cover. The lamp is a lens LED lamp, and the aluminum alloy reinforced track flat fork. The front reduction is a single-chamber dual-adjustable mode, and the rear reduction is an adjustable airbag. Yuanxing (Chengyuan brand) special off-road tires, clean surface non-ironing silent muffler. With full vehicle lighting (front headlights, rear taillights, turn signals). Digital instrument with counting sensor.
Specifications:
| Dimensions (Length x Width x Height) |
2140 x820x 1240 |
| Seat Height |
900mm |
| Wheelbase |
1460mm |
| Minimum Ground Clearance |
280mm |
| Maximum Load |
150kg |
| Steering Angle |
40 |
| Side Stand Tilt Angle |
14 |
| Ride Capacity |
1 Person |
| Dry Weight |
110kg |
| Fuel Tank Capacity |
9L |
| Front Braking System |
Disc brakes |
| Rear Braking System |
Disc brakes |
| Front Tire Size |
80/100-21 |
| Rear Tire Size |
100/90-18 |
| Battery Size |
12V/6.5Ah |
| Engine Type |
Single cylinder, water cooling, four-stroke |
| Engine displacement |
300CC |
| Bore x stroke |
72×71 |
| Compression ratio |
12.8:1 |
| Maximum power |
36Kw/h |
| Maximum torque |
43N.m |
| Maximum speed |
100Km/h |
| Start-up acceleration |
10S |
| Overtaking acceleration |
11S |
| Lubrication method |
Pressure, Splash |
| Oil volume |
1.2L |
| Clutch type |
Hydraulic Multi-plate Wet Clutch, Manual |
| Ignition method |
CDI |
| Spark plug |
A8RTC |
| Starting method |
Electric Starter |
| Transmission method |
Chain Drive |
| Final gear ratio |
13:43 |
Frequently Asked Questions:
Q1. About us:
A: Jiangmen Songfeng Import and Export Co., Ltd. is the export arm of our manufacturing facility, Yuanhua Technology Co., Ltd. We provide factory-direct pricing and strict quality control, ensuring you receive competitive products straight from the source.
Q2. Payment Terms:
A: We require 30% deposit to begin production preparation, with the remaining 70% due upon completion before loading.
Q3. Delivery Timeline:
A: Depending on the order quantity, usually around 45 working days
Q4. Customization:
A: We can meet OEM requirements and, with the customer's authorization, use the customer's brand. Displacement and other configurations can be modified upon request.
Q5. Packaging Parameters:
A: The size of SKD is 1780×460×840mm, and a 40HQ container can hold 96 units.
The size of CKD is 1400×770×440mm, and a 40HQ container can hold 147 units.
Q6. Minimum Order Quantity:
A: We usually recommend MOQ a 40HQ, which can be mixed with different complete motorcycles and spare parts. For the first order of small quantity, a quantity of 20GP is also acceptable. Appreciate your understanding that we do not handle retail exports.
Q7. After-sales Service:
We provide 24-hour online support to resolve quality issues at any time and guarantee the supply of all original spare parts to ensure your worry-free after-sales experience.
