Description:
|
ENGINE:
|
CG150
|
ENGINE TYPE
|
SINGLE CYLINDER, AIR-COOLED, FOUR-STROKE
|
|
DISPLACEMENT:
|
162CC
|
MAX. POWER:
|
8.8/8000KW/R/MIN
|
|
MAX. TORQUE:
|
11.3/6500N.M./RPM
|
IGNITION TYPE:
|
CDI
|
|
START SYSTEM:
|
ELECTRICAL/KICK
|
TRANSMISSION:
|
CHAIN DRIVE
|
|
TYRE:
|
FRONT 90/100/21 REAR 110/90/18
|
BRAKE:
|
FRONT DISC AND REAR DRUM
|
Yinxiang Power, CG150CC engine, air-cooled, electric/kick start/manual clutch, 520-13 sprocket, air-cooled, 5-speed transmission, chain drive; front 3.00-21, rear 4.10-18, deep-tooth off-road tread pattern. Front disc, rear drum, square tube swingarm; parallel front suspension, single rear shock; 2010 instrument cluster; LED turn signals; Cheetah rearview mirrors; maintenance-free battery; standard fuel tank; two-seater; rear rack; cable choke; brand new body panels; handlebar bumpers; new LED headlight with handlebar guards.
Specifications:
| Item |
Parameter |
| Dimensions (Length x Width x Height) |
2060×860×1180mm |
| Seat Height |
860mm |
| Wheelbase |
1350mm |
| Minimum Ground Clearance |
280mm |
| Maximum Load |
150kg |
| Steering Angle |
40 |
| Side Stand Tilt Angle |
13 |
| Ride Capacity |
2 Person |
| Dry Weight |
115kg |
| Fuel Tank Capacity |
11.5L |
| Front Braking System |
Disc brakes |
| Rear Braking System |
Drum brakes |
| Front Tire Size |
90/100/21 |
| Rear Tire Size |
110/90/18 |
| Battery Size |
12V/6.5Ah |
| Engine Type |
Single cylinder, air-cooled, four-stroke |
| Engine displacement |
162 |
| Bore x stroke |
62×53 |
| Compression ratio |
9.0:1 |
| Maximum power |
8.8/8000(kW/r/min) |
| Maximum torque |
11.3/6500(N·m/r/min) |
| Maximum speed |
90km/h |
| Start-up acceleration |
14S |
| Overtaking acceleration |
13S |
| Lubrication method |
Pressure, Splash |
| Oil volume |
1.1L |
| Clutch type |
Multi-plate wet clutch, manual |
| Ignition method |
CDI |
| Spark plug |
A8RTC |
| Starting method |
Electric kick starter |
| Transmission method |
Chain drive |
| Final gear ratio |
15:43 |
Frequently Asked Questions:
Q1. About us:
A: Jiangmen Songfeng Import and Export Co., Ltd. is the export arm of our manufacturing facility, Yuanhua Technology Co., Ltd. We provide factory-direct pricing and strict quality control, ensuring you receive competitive products straight from the source.
Q2. Payment Terms:
A: We require 30% deposit to begin production preparation, with the remaining 70% due upon completion before loading.
Q3. Delivery Timeline:
A: Depending on the order quantity, usually around 45 working days.
Q4. Customization:
A: We can meet OEM requirements and, with the customer's authorization, use the customer's brand. Displacement and other configurations can be modified upon request.
Q5. Packaging Parameters:
A: The size of SKD is 1830×460×840mm, and a 40HQ container can hold 96 units.
The size of CKD is 1400×760×380mm, and a 40HQ container can hold 147 units.
Q6. Minimum Order Quantity:
A: We usually recommend MOQ a 40HQ, which can be mixed with different complete motorcycles and spare parts. For the first order of small quantity, a quantity of 20GP is also acceptable. Appreciate your understanding that we do not handle retail exports.
Q7. After-sales Service:
We provide 24-hour online support to resolve quality issues at any time and guarantee the supply of all original spare parts to ensure your worry-free after-sales experience.
