YH250ADV-C

Large Image : YH250ADV-C

Product Details:

Place of Origin:	Chongqing, China
Brand Name:	OEM
Model Number:	YH250ADV-C

Payment & Shipping Terms:

Minimum Order Quantity:	40HQ (93PCS)
Price:	Negotiable
Packaging Details:	SKD 93PCS/40HQ，CKD 120PCS/40HQ
Delivery Time:	45 work days
Supply Ability:	Customized

Contact Now Chat Now

YH250ADV-C

Description

Engine:	TM250	Displacement:	250CC
Max. Power:	12/7500(kw/r/min)	Max. Torque:	18/6000(N·m/r/min)
Ignition Type:	CDI	Start System:	Electrical / Kick
Front Braking:	Disc Brakes	Rear Braking:	Disc Brakes
Engine Type:	Single-cylinder, Oil-cooled, 4-valve, 4-stroke	MOQ:	93PCS

Description:

TM250 oil-cooled engine, four valves, carburetor, mesh wheels, front and rear disc brakes, inverted front shock, independent rear air chamber shock, digital instrument panel, knife-edge flat fork, aluminum rear armrest, wraparound front bumper, LED handlebar guard, lighting system, ADV tires, engine guard included.

Specifications:

Item	Parameter
Dimensions (Length x Width x Height)	2150×860×1200mm
Seat Height	890mm
Wheelbase	1435mm
Minimum Ground Clearance	240mm
Maximum Load	150kg
Steering Angle	35
Side Stand Tilt Angle	14
Ride Capacity	2 Person
Dry Weight	135kg
Fuel Tank Capacity	14L
Front Braking System	Disc brakes
Rear Braking System	Disc brakes
Front Tire Size	90/100/19
Rear Tire Size	120/100-18
Battery Size	12V/7Ah
Engine Type	Single-cylinder, oil-cooled, 4-valve, 4-stroke
Engine displacement	250CC
Bore x stroke	67×62.5
Compression ratio	9:1
Maximum power	12/7500(kw/r/min)
Maximum torque	18/6000(N·m/r/min)
Maximum speed	100Km/h
Start-up acceleration	14S
Overtaking acceleration	13S
Lubrication method	Pressure, Splash
Oil volume	1.2L
Clutch type	Multi-plate wet clutch, manual
Ignition method	CDI
Spark plug	A8RTC
Starting method	Electric starter
Transmission method	Chain drive
Final gear ratio	13:40

Packaging parameters:

	SKD	CKD
Package Dimensions (Length x Width x Height)	1890×460×840mm	1480×760×380mm
Gross Weight	156kg	125kg
Quantity	93(40HQ)	120(40HQ)

Frequently Asked Questions:

Q1. About us:

A: Jiangmen Songfeng Import and Export Co., Ltd. is the export arm of our manufacturing facility, Yuanhua Technology Co., Ltd. We provide factory-direct pricing and strict quality control, ensuring you receive competitive products straight from the source.

Q2. Payment Terms:

A: We require 30% deposit to begin production preparation, with the remaining 70% due upon completion before loading.

Q3. Delivery Timeline:

A: Depending on the order quantity, usually around 45 working days

Q4. Customization:

A: We can meet OEM requirements and, with the customer's authorization, use the customer's brand. Displacement and other configurations can be modified upon request.

Q5. After-sales Service:

A: We provide 24-hour online support to resolve quality issues at any time and guarantee the supply of all original spare parts to ensure your worry-free after-sales experience.
